Sidekick 640 Mini Thermal Monocular

Armasight
SKU:
TAVT66MN9SIDE101
|
UPC:
810081911672
$2,999.00
(5 reviews)
Current Stock:

The Sidekick 640 is the smallest fully multi-functional 12-micron 640 thermal imaging monocular on the market. This unit boasts a fast 60Hz frame rate for smooth operation and industry-best, outstanding visual acuity, based on Armasight’s Iron Wolf thermal technology platform. Weighing under 250 grams, the Sidekick can be used as a handheld mini-monocular or can be headset/helmet mounted utilizing the built-in mini-rail for hands-free operation. The high definition 1024×768 OLED display provides a crisp image, with iconography providing key information. The Sidekick utilizes simplified 3 button controls that allow for easy manipulation in the field and offers one-touch in-unit video recording to capture all of your experiences.

Features

  • Multiple Color Palettes
  • Intuitive 3-Button Control
  • 1.5h Runtime on 1 x CR123A Battery, 5.5h on 2 Batteries with Included Battery Extender
  • Image Detail Enhancement
  • Dovetail Mini-Rail Included for Helmet Mounting (with Optional Mount)
  • Works with Rayvn Group Modular Bridge Mount for Helmet-Mounting with PVS-14, MNVD, or Second Sidekick (sold separately)
  • Ability to Shift Thermal Image to Collimate Sidekick Image with NVD when Bridged
  • Video Recording & Image Capture
  • USB Video Stream
  • USB-C Interface for External Devices
  • Compass
  • Battery Status Indicator
  • ULTEM Composite Body and Ergonomic Design
  • Designed and Assembled in the USA from U.S. and Global Component

Package Includes

  • Sidekick 640 Mini Thermal Monocular
  • 2 x CR123A Battery
  • USB-C Cable
  • Battery Extender
  • Lens Cloth
  • Soft Case
  • Product Manual
Detector Type:
ArmaCORE™ 640x480 12um Thermal Core
Refresh Rate:
60 Hz
Thermal Sensitivity:
NETD < 40mK
Detection Range:
709m On a Human Sized Target
Recognition Range:
177m on a Human Sized Target
Identification Range:
111m on a Human Sized Target
Eye Relief:
15mm
Field of View:
24.16° x 17.37°
Optical Magnification:
1x
Digital Zoom:
1x - 4x
Display:
XGA (1024 x 768) OLED
Wireless:
None
Graphics:
Active On-Screen Graphics and Iconology
Lens System:
F/1.00; 19mm manual focus
Diopter Adjustment:
-5 to +5 dpt
Power Supply:
1 x CR123A or 2 x CR123A / 1 x 16650
Battery Life:
1x / 2x CR123A - 1.5h / 5.5h at 20°C (68°F)
Low Battery Indicator:
Yes
Memory:
4 Hours of Video
Image Processing:
Digital Enhancement
Environmental Rating:
IP67
Operating Temperature:
-40° C to +50° C (-40° F to + 122° F)
Dimensions:
104.90 x 65.28 x 59.69 mm / 4.13 x 2.57 x 2.35 in
Weight:
254g / 0.56lbs. w/ rubber eyecup; no battery
Warranty:
3 years w/ registration
Color:
Black
